Clean Room Differential Pressure Monitor (Temp, RH, Diff. Pressure) for Pharma Clean Rooms, Hospitals, APIs, Bulk Drugs Factory Calibration Certificate Model: (AI-CRM3-1-1) External Sensor
Product details
| Management number | 210906180 | Release Date | 2026/04/04 | List Price | $971.89 | Model Number | 210906180 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Ace AI-CRM 3-1-1 Pharma Clean Room Monitor’s sensor for humidity & temperature is externally provided so that the sensor can be mounted in the operation theatre & the display can be outside the operation theatre. The sensor for humidity & temperature is externally provided so that the sensor can be mounted in the clean rooms & the Display can be outside the Clean rooms. The differential pressure sensor is built inside the Clean Room Monitor with 2 Nos. Hose Nipples for room & corridor connection.
- Model: AI-CRM3-1-1 | Measuring Parameters: Temperature, Humidity, Differential Pressure | Temperature Range: -30.0 to +50.0 Deg.C; Accuracy: ± 0.5°C; Resolution: 0.1°C | Humidity Range: 0.0 to 100.0%RH; Accuracy: ± 1.8% for 10 to 95% RH; Resolution: 0.1% RH | Differential Pressure Range: -500 to +500 pascals; Accuracy: +/- 0.5% F.S; Resolution: 1 pascal |
- Display: 3 Line Red 7 segment LED display of Height 0.8” | Differential Pressure Entry: 2 Nos. 4 mm. Hose nipples at top of clean room monitor enclosure entry | Setting: By 4 keys inside the instrument | Buzzer: Integrated buzzer for alarm Hi & Lo in case of process violation of any of the 3 parameters | Supply Voltage: 24VDC, 500mA |
- Mounting: Wall mounting / Modular Wall mounting with stainless steel front flush plate for clean rooms | Sensors: External Humidity & Temperature sensor in stainless steel front flush plate enclosure. Built-in Differential Pressure sensor with brass hose nipples (chrome plated) for differential pressure at rear (4mm X 2 Nos.) |
- Enclosure: M.S. Powder coated body with stainless steel front plate for Modular wall mounting/ optional brick wall mounting | Dimensions: Enclosure: 110(W) X 150(H) X 30(D) mm. & Stainless-Steel front plate: 180(W) X 200 (H) mm. | weight: 700 gms. Approx.
- Supply Scope: 1 Unit of AI-CRM3-1-1 Clean Room Monitor, Power Adaptor, Instruction Manual and Factory Calibration Certificate | Applications: Pharma Clean Rooms, Hospitals, API’s, Bulk Drugs, Green House, Test Plants, Electronic Hardware manufacturing plants.
| Brand Name | INSTRUKART |
|---|---|
| Item Weight | 700 Grams |
| Manufacturer | INSTRUKART |
| Material Type | Stainless Steel |
| Item Dimensions | 1.18 x 4.33 x 5.91 inches |
| Included Components | AI-CRM3-1-1 Clean Room Monitor, Power Adaptor, Instruction Manual |
| Warranty Description | no Warranty |
